Boom Barrier For Toll Plaza (0.6 Second)
Model No: ETS-BB 06
Description
ETS BB 06 is the fastest barrier available in the boom barrier range offered by ETS RFID with a up -down speed of 0.5 – 0.6 seconds. This high-speed automatic barrier has a maximum boom length of 3 meters. Powered by DC Servo Motor, it is primarily used for Toll Plaza projects which require fast and robust movement for heavy traffic. This highly rugged and durable barrier is Bi-Directional and fully compatible with RFID Readers and IOT Controllers to grant automatic entry and exit to authorized vehicles from the Toll Plaza / campus.
Features
Speed 0.5 - 06 Sec.
Length 3 meters
DC Servo Motor
Anti Crash Function
Auto Close Function
Compatible: RFID, Controller,Loop, Photocell
Application Areas
Toll Plaza
Business Park
Hospitals & Hotels
Parking Lots for Malls
| Model | ETS-BB 06 |
| Automation Grade | Automatic |
| Speed | 0.5 second – 0.6 second |
| Max Boom Arm Length | 3 Meters |
| Motor Input Power | 300W |
| Input power Supply Voltage | 220 V AC (+- 10%) |
| Max Torque | 480 NM with 90 Rotation Min. |
| Anti-Crash | Built in. Reverse on hit by vehicle |
| Boom Type | Carbon Steel Straight |
| Boom Weight | Approx. 3 kg |
| Boom Dimensions | 46 mm. x 79 mm. |
| Base Material | Iron |
| Frequency | 50 / 60 Hz |
| Rated Power | 100 Watts |
| Duty Cycle | 100% |
| Working Temp. | -35 to 75 degree cel. |
| Relative Humidity | ≤ 90% |
| Protection | IP 54 Rated |
| Net Weight | 64 kg. |
| Remote Working Range | ≥ 30m |
| Compatibility | All Type of RFID Readers, IOT Controller, Loop, Photocells (Anti Crash Sensor), Ticket Dispensing Machines etc. |
| Accessories | Remote, Push Button, Loop, Photocells |
| Counter Balance | 3 tension spring crank transmission design. Electronic Clutch design |
| MTBF | 10.5 million |
