High Temperature RFID Resistant Tag
Model No: ETS-RTHT 4015
Features
865 MHZ-928 MHz
EPC Class 1 Gen2 ISO 18000-6C
Upto 260°С
IP68
Read Range: Upto 6 Meters
Chip: Ucode 8
Compact Size & Light Weight
Data Retention 50 Years
Mounting Methods
Chemical & Water High Temperature Resistant
Shock & Vibration Resistent
Custom Laser Printing
Application Areas
Oil and Gas
Automobile
Chemical & Paints
Injection Molding & Die Casting
Sterilization in medical & hospital
| Functional Specifications | |
| Protocol | EPC Class1 Gen2, ISO18000-6C |
| Frequency | (US) 902-928MHz, (EU) 865-868MHz |
| IC type | UCODE8 |
| Memory | EPC 128bits, USER 0 bits, TID 96bits |
| Write Cycles | 100,000 times |
| Functionality | Read/write |
| Data Retention | 50 Years |
| Applicable Surface | Metal Surfaces |
| Read Range(On Metal): (Fix Reader) | 6.0m, (US) 902-928MHz, On Metal;1.7m, (US) 902-928MHz, Off Metal 6.0m, (EU) 865-868MHz, On Metal;1.7m, (EU) 865-868MHz, Off Metal |
| Read Range(On Metal): (Handheld Reader) | 3.0m, (US) 902-928MHz, On Metal;1.2m,(US) 902-928MHz, Off Metal 3.0m, (EU) 865-868MHz, On Metal;1.2m,(EU) 865-868MHz, Off Metal |
| Warranty | 1 Year |
| Physical Specification | 1 Year |
| Size | 40.0x15.0mm, Hole: D2.5mmx2 |
| Thickness | 10.0mm |
| Material | PEEK |
| Colour | Black |
| Mounting Methods | Screw |
| Weight | 6g |
| Environmental Specification | |
| IP Rating | IP68 |
| Storage Temperature | -40°С to +260°С,+300°С100 hours |
| Operation Temperature | -40°С to +150°С |
| Certifications | Reach Approved, RoHS Approved, CE Approved, ATEX Approved. |
