Proximity Card Reader
Model No: ETS-RD 03
Description
ETS-RD 03 is a small and compact RFID Proximity Reader which works on 125 khz frequency. With an inbuilt LED and Buzzer, it has a read and write range of 12 cm and can be connected to the PC server via USB interface. It can read proximity EM Cards like EM4001, EM4100, EM4200, TK4100 etc. It works on plug and play mode and does not require installation of any specific driver or software i.e. Once the reader is plugged into the system, it will automatically be detected as an interfacing device. It is most widely used for encoding (registration) of cards and its authentication for various applications
Features
Frequency: 125 KHz
Supports: Em4001, Em4100, Em4200, Tk4100
Compact Design
Read Range: Upto 12cm
Plug and Play
Interface: USB / Rs 232
Inbuilt LED & Buzzer
Application Areas
Attendance Management
Conference / Event Registration
Access Control
Library Card
Card Encoding & Registration
Water Meter
Electricity Meter
Gas Meter
Card Authentication
| Model Number | ETS-RD 03 |
| Frequency | 125 khz |
| Card Support | EM4001, EM4100, EM4200, TK4100 and its compatible RFID |
| Data Transmission Speed | 106 kbit per second |
| Interface | USB |
| Data Output Format | First 10digits of the ID card and other data output format can be customization |
| Range | Up to 120 mm (12 cm) |
| Dimension | 108 mm x 78 mm x 20 mm |
| Weight | 100 gram |
| Colour | Black |
| Power Supply | Direct USB power connectivity through attached PC/Laptop |
| Buzzer and LED | Yes |
| Housing Material | ABS Plastic |
| Temperature | -10 to +70 degree Celsius |
| USB Length | 1 mt. |
| OS Compatibility | Windows 32, 64, Linux, Android supported |
| Quality Assurance | 100% quality tested |
| Compliance | CCID, CE |
