| Electrical Specifications | | |
| Air Interface Protocol | ISO/IEC 11784/85, Animal Mode, FDX, HDX | |
| Operational Frequency | 134.2KHz | |
| Chip | SIC 7999 HDX
R/W user data memory of 6x32 (192 bits) for database management
192 Bits, Extended Read Range HDX
Supporting user access to factory unique ROM (UID),
preventing chips from cloning
Direct Access/Write mode
Read-only Animal ID section when no command received
Read/Write or OTP configuration | |
| Read Range | 80 cm | |
| Operating Temperature | -40°C to +80°C | |
| Storage Temperature | -40°C to +120°C | |
| Ingress Protection Rating | IP67 | |
| Attachment | Male pin by applicator | |
| Expected Lifetime | Up to 5 years is normal operating conditions | |
| Physical and Mechanical Specifications | | |
| Model | Close Cap | Close Cap |
| Diameter | Ø30.4mm | Ø3.4mm |
| Height | 15.50mm | 12mm |
| Weight | 7.2gm | 7gm |
| Encasement | TPU | |
| Quality Assurance | 100% reader tested | |
| Colour | yellow | |
| Chemical Resistance | | |
| Resistant to continuous exposure to salt water for 2 hours | | |
| Resistant to continuous exposure to motor oil for 2 hours | | |
| Additionally, abrasion resistant against HCL and IPA | | |
| Additional Services | | |
| Pre-encoding | On request | |
| Customization | Logo / text printing on request | |
