RFID Apparel Tag
Model No: ETS-RT 07D
Description
ETS-RD 07D is compact size UHF Tag meant for application on retail and apparel industry. It provides a high read write reliability of upto 4 meters and excellent performance for closely stacked clothes. The tag is fully compliant with global GS1 UHF Gen 2 standards.
Features
865 MHz - 928MHz
EPC Gen1 ISO 18000-63
Range upto 4 meter
Upto 200 Wash Cycle
Water Resistant
Chemical Proof
Linen Friendly
Application Areas
Retail
Apparel
Inventory Management
Cloth Boutique
Fashion Shows
| Physical Specification | |
| Inlay size | 54 mm X 34 mm & 74 mm X 18 mm |
| Label size (customizable) | 60 mm X 57 mm |
| Adhesive | NA |
| Delivery format | Reel |
| No. of labels/Reel | 10,000 pcs/reel |
| Pitch | NA |
| Core Inner diameter | 76 mm / 3 in |
| Available face material | Taffeta |
| RFID Specifications | |
| Operating Mode | Passive |
| Frequency Band | UHF 860-960 MHz |
| RF Protocol | ISO/IEC 18000-63 Type C |
| IC | NXP UCODE 8 & M730 |
| Functionality | Read/write |
| EPC Memory | 128-bit |
| TID Memory | 96-bit / 48-bit unique serial number |
| User Memory | NA |
| Web Width | 48mm / 2 in |
| Access Password | 32 |
| Kill Password | 32 |
| Write cycle endurance | 200000 cycles |
| Read Range | up to 4 meter |
| Tamper Proof | No |
| ROHs | EU Directive 2011/65/EC & Directive (EU) 2015/863 |
| Certificate | ARC |
| Environmental Resistances | |
| Operating Temp. | -40°C to 85°C, -40°F to 185°F |
| Ideal storage condition | 5-95% non condensing |
| Relative Humidity | No |
| UV Resistant | NA |
| Personalization Options | |
| Encoding | Possible |
| Customized Printing | Possible |
